Everything you need
Roofing Accessories
Complete System
Roofing Sheets
- Roofing sheets in your chosen material and length
- Calculate your requirements based on your roof area plus 10% allowance for wastage
Fixings & Fasteners
- Roofing screws (weather sealed)
- Hex Head Type 17 Screw with EPDM Washers for timber supports
- Allow 8-10 screws per square metre of roof area
Ridge Capping & Flashings
- Ridge capping for rooftop peaks
- Barge flashings for gable ends
- Apron flashings for wall junctions
- Valley gutters for roof valleys
Guttering System
- Quad or fascia gutters (half round or flat back)
- Downpies & brackets
Support Structure
- Purlins/battens (if not existing)
- Appropriate spacing to suit the corrugated profile

IMAGE CREDIT:Â Â https://colorbond.com/
Photo by:Â Matthew Moyes | Built by: Phil Kelleher Homes
Installation Overview

IMAGE CREDIT: https://colorbond.com/inspiration/gallery
Builder:Â Saltbox Building | Designed by Rama Architects
Measure & plan
Calculate how many sheets you need. Mark purlin positions.
Prepare the structure
Install purlins and roof batterns, ensure they are correctly spaced and level.
Add guttering
Complete the rooftop water management system, including downpipes.
Install roofing sheets
Begin at one end, overlap sheets correctly, and maintain straight lines.
Secure sheets
Use the appropriate screws in the correct positions.
Install flashings
Seal all joints and roof penetrations.
Wash down
Thoroughly wash down to clean off swarf (metal shavings)
Frequently Asked Questions
Roofing insulation is a barrier layer that is installed under a rooftop. It reduces and slows heat transfer, helping keep the interior of the building warmer in winter and cooler in summer.
Not only does insulating your roof enhance comfort inside the home or other premises, but it also improves the building’s energy efficiency and can actively reduce energy bills.
Installing a COLORBOND® roof effectively requires items including self-drilling screws that meet Australian standard AS3566.1 Class 3 (or above) and which feature a neoprene or EPDM sealing washer. Select screws that are painted in the exact COLORBOND® colour as your rooftop sheeting to ensure a seamless finish.
It’s simple! Just get in touch with us to get the ball rolling.
